Strainer Length* Choose an option Short Long
Mesh* Choose an option OverScreen - 10 x 10 mesh (1905 microns) OverScreen - 12 x 12 mesh (1524 microns) OverScreen - 14 x 14 mesh (1295 microns) OverScreen - 16 x 16 mesh (1130 microns) OverScreen - 18 x 18 mesh (980 microns) OverScreen - 20 x 20 mesh (860 microns) OverScreen - 24 x 24 mesh (704 microns) OverScreen - 30 x 30 mesh (516 microns) OverScreen - 40 x 40 mesh (381 microns) OverScreen - 50 x 50 mesh (280 microns) OverScreen - 60 x 60 mesh (234 microns) OverScreen - 80 x 80 mesh (178 microns) OverScreen - 100 x 100 mesh (140 microns) OverScreen - 120 x 120 mesh (117 microns) OverScreen - 150 x 150 mesh (104 microns) OverScreen - 200 x 200 mesh (74 microns)
Mesh* Choose an option OverScreen - 10 x 10 mesh (1905 microns) OverScreen - 12 x 12 mesh (1524 microns) OverScreen - 14 x 14 mesh (1295 microns) OverScreen - 16 x 16 mesh (1130 microns) OverScreen - 18 x 18 mesh (980 microns) OverScreen - 20 x 20 mesh (860 microns) OverScreen - 24 x 24 mesh (704 microns) OverScreen - 30 x 30 mesh (516 microns) OverScreen - 40 x 40 mesh (381 microns) OverScreen - 50 x 50 mesh (280 microns) OverScreen - 60 x 60 mesh (234 microns) OverScreen - 80 x 80 mesh (178 microns) OverScreen - 100 x 100 mesh (140 microns) OverScreen - 120 x 120 mesh (117 microns) OverScreen - 150 x 150 mesh (104 microns) OverScreen - 200 x 200 mesh (74 microns)
Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S010 (Old Item No. 5000010) 2.5″, 3.0″, and 4.0″ 535S010 (Old Item No. 5000160)
OverScreen - 10 x 10 mesh (1905 microns)
0.075" opening, 0.025" wire diameter 3" dia. x 10-7/8"" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT)
Old Item Number: 5000010 OverScreen - 10 x 10 mesh (1905 microns)
0.075" opening, 0.025" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT)
Old Item Number: 5000160 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L010 (Old Item No. 5000510) 2.5″, 3.0″, and 4.0″ 535L010 (Old Item No. 5000310)
OverScreen - 10 x 10 mesh (1905 microns)
0.075" opening, 0.025" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG)
Old Item Number: 5000510 OverScreen - 10 x 10 mesh (1905 microns)
0.075" opening, 0.025" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG)
Old Item Number: 5000310 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S012 (Old Item No. 5000020) 2.5″, 3.0″, and 4.0″ 535S012 (Old Item No. 5000170)
OverScreen - 12 x 12 mesh (1524 microns)
0.060'' opening, 0.023" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT)
Old Item Number: 5000020 OverScreen - 12 x 12 mesh (1524 microns)
0.060" opening, 0.023" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT)
Old Item Number: 5000170 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L012 (Old Item No. 5000520) 2.5″, 3.0″, and 4.0″ 535L012 (Old Item No. 5000320)
OverScreen - 12 x 12 mesh (1524 microns)
0.060" opening, 0.023" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG)
Old Item Number: 5000520 OverScreen - 12 x 12 mesh (1524 microns)
0.060" opening, 0.023" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG)
Old Item Number: 5000320 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S014 (Old Item No. 5000030) 2.5″, 3.0″, and 4.0″ 535S014 (Old Item No. 5000180)
OverScreen - 14 x 14 mesh (1295 microns)
0.051'' opening, 0.020" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT)
Old Item Number: 5000030 OverScreen - 14 x 14 mesh (1295 microns)
0.051" opening, 0.020" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT)
Old Item Number: 5000180 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L014 (Old Item No. 5000530) 2.5″, 3.0″, and 4.0″ 535L014 (Old Item No. 5000330)
OverScreen - 14 x 14 mesh (1295 microns)
0.051" opening, 0.020" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG)
Old Item Number: 5000530 OverScreen - 14 x 14 mesh (1295 microns)
0.051" opening, 0.020" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG)
Old Item Number: 5000330 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S016 (Old Item No. 5000040) 2.5″, 3.0″, and 4.0″ 535S016 (Old Item No. 5000190)
OverScreen - 16 x 16 mesh (1130 microns)
0.0445" opening, 0.018" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N R )
Old Item Number: 5000040 OverScreen - 16 x 16 mesh (1130 microns)
0.0445" opening, 0.018" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f)All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N R )
Old Item Number: 5000190 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L016 (Old Item No. 5000540) 2.5″, 3.0″, and 4.0″ 535L016 (Old Item No. 5000340)
OverScreen - 16 x 16 mesh (1130 microns)
0.0445" opening, 0.018" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N R )
Old Item Number: 5000540 OverScreen - 16 x 16 mesh (1130 microns)
0.0445" opening, 0.018" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N R )
Old Item Number: 5000340 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S018 (Old Item No. 5000050) 2.5″, 3.0″, and 4.0″ 535S018 (Old Item No. 5000200)
OverScreen - 18 x 18 mesh (980 microns)
0.0386" opening, 0.017" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT)
Old Item Number: 5000050 OverScreen - 18 x 18 mesh (980 microns)
0.0386" opening, 0.017" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT)
Old Item Number: 5000200 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L018 (Old Item No. 5000550) 2.5″, 3.0″, and 4.0″ 535L018 (Old Item No. 5000350)
OverScreen - 18 x 18 mesh (980 microns)
0.0386" opening, 0.017" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG)
Old Item Number: 5000550 OverScreen - 18 x 18 mesh (980 microns)
0.0386" opening, 0.017" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG)
Old Item Number: 5000350 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S020 (Old Item No. 5000060) 2.5″, 3.0″, and 4.0″ 535S020 (Old Item No. 5000210)
OverScreen - 20 x 20 mesh (860 microns)
0.0340" opening, 0.016" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N P )
Old Item Number: 5000060 OverScreen - 20 x 20 mesh (860 microns)
0.0340" opening, 0.016" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N P )
Old Item Number: 5000210 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L020 (Old Item No. 5000560) 2.5″, 3.0″, and 4.0″ 535L020 (Old Item No. 5000360)
OverScreen - 20 x 20 mesh (860 microns)
0.0340" opening, 0.016" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N P )
Old Item Number: 5000560 OverScreen - 20 x 20 mesh (860 microns)
0.0340" opening, 0.016" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N P )
Old Item Number: 5000360 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S024 (Old Item No. 5000070) 2.5″, 3.0″, and 4.0″ 535S024 (Old Item No. 5000220)
OverScreen - 24 x 24 mesh (704 microns)
0.0277" opening, 0.014" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT)
Old Item Number: 5000070 OverScreen - 24 x 24 mesh (704 microns)
0.0277" opening, 0.014" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT)
Old Item Number: 5000220 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L024 (Old Item No. 5000570) 2.5″, 3.0″, and 4.0″ 535L024 (Old Item No. 5000370)
OverScreen - 24 x 24 mesh (704 microns)
0.0277" opening, 0.014" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG)
Old Item Number: 5000570 OverScreen - 24 x 24 mesh (704 microns)
0.0277" opening, 0.014" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG)
Old Item Number: 5000370 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S030 (Old Item No. 5000080) 2.5″, 3.0″, and 4.0″ 535S030 (Old Item No. 5000230)
OverScreen - 30 x 30 mesh (516 microns)
0.0203" opening, 0.013" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N T )
Old Item Number: 5000080 OverScreen - 30 x 30 mesh (516 microns)
0.0203" opening, 0.013" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N T )
Old Item Number: 5000230 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L030 (Old Item No. 5000580) 2.5″, 3.0″, and 4.0″ 535L030 (Old Item No. 5000380)
OverScreen - 30 x 30 mesh (516 microns)
0.0203" opening, 0.013" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N T )
Old Item Number: 5000580 OverScreen - 30 x 30 mesh (516 microns)
0.0203" opening, 0.013" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N T )
Old Item Number: 5000380 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S040 (Old Item No. 5000090) 2.5″, 3.0″, and 4.0″ 535S040 (Old Item No. 5000240)
OverScreen - 40 x 40 mesh (381 microns)
0.0150" opening, 0.010" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N J )
Old Item Number: 5000090 OverScreen - 40 x 40 mesh (381 microns)
0.0150" opening, 0.010" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N J )
Old Item Number: 5000240 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L040 (Old Item No. 5000590) 2.5″, 3.0″, and 4.0″ 535L040 (Old Item No. 5000390)
OverScreen - 40 x 40 mesh (381 microns)
0.0150" opening, 0.010" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N J )
Old Item Number: 5000590 OverScreen - 40 x 40 mesh (381 microns)
0.0150" opening, 0.010" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N J )
Old Item Number: 5000390 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S050 (Old Item No. 5000095) 2.5″, 3.0″, and 4.0″ 535S050 (Old Item No. 5000245)
OverScreen - 50 x 50 mesh (280 microns)
0.0110" opening, 0.009" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N N )
Old Item Number: 5000095 OverScreen - 50 x 50 mesh (280 microns)
0.0110" opening, 0.009" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N N )
Old Item Number: 5000245 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L050 (Old Item No. 5000595) 2.5″, 3.0″, and 4.0″ 535L050 (Old Item No. 5000395)
OverScreen - 50 x 50 mesh (280 microns)
0.0110" opening, 0.009" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N N )
Old Item Number: 5000595 OverScreen - 50 x 50 mesh (280 microns)
0.0110" opening, 0.009" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N N )
Old Item Number: 5000395 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S060 (Old Item No. 5000100) 2.5″, 3.0″, and 4.0″ 535S060 (Old Item No. 5000250)
OverScreen - 60 x 60 mesh (234 microns)
0.0092" opening, 0.0075" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N F )
Old Item Number: 5000100 OverScreen - 60 x 60 mesh (234 microns)
0.0092" opening, 0.0075" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N F )
Old Item Number: 5000250 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L060 (Old Item No. 5000600) 2.5″, 3.0″, and 4.0″ 535L060 (Old Item No. 5000400)
OverScreen - 60 x 60 mesh (234 microns)
0.0092" opening, 0.0075" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N F )
Old Item Number: 5000600 OverScreen - 60 x 60 mesh (234 microns)
0.0092" opening, 0.0075" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N F )
Old Item Number: 5000400 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S080 (Old Item No. 5000110) 2.5″, 3.0″, and 4.0″ 535S080 (Old Item No. 5000260)
OverScreen - 80 x 80 mesh (178 microns)
0.0070" opening, 0.0055" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N L )
Old Item Number: 5000110 OverScreen - 80 x 80 mesh (178 microns)
0.0070" opening, 0.0055" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N L )
Old Item Number: 5000260 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L080 (Old Item No. 5000610) 2.5″, 3.0″, and 4.0″ 535L080 (Old Item No. 5000410)
OverScreen - 80 x 80 mesh (178 microns)
0.0070" opening, 0.0055" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N L )
Old Item Number: 5000610 OverScreen - 80 x 80 mesh (178 microns)
0.0070" opening, 0.0055" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N L )
Old Item Number: 5000410 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S100 (Old Item No. 5000120) 2.5″, 3.0″, and 4.0″ 535S100 (Old Item No. 5000270)
OverScreen - 100 x 100 mesh (140 microns)
0.0055" opening, 0.0045" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N K )
Old Item Number: 5000120 OverScreen - 100 x 100 mesh (140 microns)
0.0055" opening, 0.0045" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N K )
Old Item Number: 5000270 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L100 (Old Item No. 5000620) 2.5″, 3.0″, and 4.0″ 535L100 (Old Item No. 5000420)
OverScreen - 100 x 100 mesh (140 microns)
0.0055" opening, 0.0045" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N K )
Old Item Number: 5000620 OverScreen - 100 x 100 mesh (140 microns)
0.0055" opening, 0.0045" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N K )
Old Item Number: 5000420 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S120 (Old Item No. 5000130) 2.5″, 3.0″, and 4.0″ 535S120 (Old Item No. 5000280)
OverScreen - 120 x 120 mesh (117 microns)
0.0046"" opening, 0.0037" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N H )
Old Item Number: 5000130 OverScreen - 120 x 120 mesh (117 microns)
0.0046" opening, 0.0037" wire diameter 3-1/2" dia. x 10-7/8" lg. (119.57 sq/in or 0.83 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N H )
Old Item Number: 5000280 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L120 (Old Item No. 5000630) 2.5″, 3.0″, and 4.0″ 535L120 (Old Item No. 5000430)
OverScreen - 120 x 120 mesh (117 microns)
0.0046" opening, 0.0037" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N H )
Old Item Number: 5000630 OverScreen - 120 x 120 mesh (117 microns)
0.0046" opening, 0.0037" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N H )
Old Item Number: 5000430 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S150 (Old Item No. 5000140) 2.5″, 3.0″, and 4.0″ 535S150 (Old Item No. 5000290)
OverScreen - 150 x 150 mesh (104 microns)
0.0041" opening, 0.0026" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N M )
Old Item Number: 5000140 OverScreen - 150 x 150 mesh (104 microns)
0.0041" opening, 0.0026" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N M )
Old Item Number: 5000290 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L150 (Old Item No. 5000640) 2.5″, 3.0″, and 4.0″ 535L150 (Old Item No. 5000440)
OverScreen - 150 x 150 mesh (104 microns)
0.0041" opening, 0.0026" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N M )
Old Item Number: 5000640 OverScreen - 150 x 150 mesh (104 microns)
0.0041" opening, 0.0026" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N M )
Old Item Number: 5000440 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530S200 (Old Item No. 5000150) 2.5″, 3.0″, and 4.0″ 535S200 (Old Item No. 5000300)
OverScreen - 200 x 200 mesh (74 microns)
0.0029" opening, 0.0021" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N S )
Old Item Number: 5000150 OverScreen - 200 x 200 mesh (74 microns)
0.0029" opening, 0.0021" wire diameter 3" dia. x 10-7/8" lg. (102.49 sq/in or 0.71 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (SHORT) (Ref P/N S )
Old Item Number: 5000300 Strainer Line Size and Item No.* Choose an option 1.0″, 1.5″, and 2.0″ 530L200 (Old Item No. 5000650) 2.5″, 3.0″, and 4.0″ 535L200 (Old Item No. 5000450)
OverScreen - 200 x 200 mesh (74 microns)
0.0029" opening, 0.0021" wire diameter 3" dia. x 30-3/4" lg. (289.81 sq/in or 2.01 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 1", 1.5", and 2.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N S )
Old Item Number: 5000650 OverScreen - 200 x 200 mesh (74 microns)
0.0029" opening, 0.0021" wire diameter 3-1/2" dia. x 30-3/4" lg. (338.11 sq/in or 2.35 s/f) All material 316L SS. Fits Perforated Back-Up Tube from a 2.5", 3.0" and 4.0" Inline or Side Inlet Strainer Assembly (LONG) (Ref P/N S )
Old Item Number: 5000450 Name
